Bowles Corporation’s UW-7 Ultrasound Wattmeter provides accurate verification and calibration of therapeutic ultrasound devices.
Dimensions: 8.5" W, 12"L, 7.25" H
Weight: 8.25 lbs (3.74kg)
Heavy-cast frame firmly supports the rugged straight bar load cell, ensuring faster technician on-site visits and protection of the load cell from damage during transit.
Support Ring Sets provide precise sound head centering and alignment for accurate readings.
Only requires 375ml of degassed water, greatly reducing degassed water requirements.
Power measurement range: 0.10 watt to 30-watt.
Function Check Weights: 75g or 200g
Extremely fast 2-second readout stabilization.
2.65"(6.7cm) diameter sound head maximum
Display: High contrast, backlit
Selectable readout in watts or grams.
Power: 120V or 240VAC 50-60 Hz standard.
Accuracy = ± 3% + one count reading.
Includes soft pack protective carrying case.
CE Approved
